A connector pair alone is not the whole specification. Read both port types, required fibre, number of paths and physical route together.
LC and SC name different connector formats. Read each device or panel port specification, then choose LC/UPC-LC/UPC, LC/UPC-SC/UPC or SC/UPC-SC/UPC from the catalogue. Do not force a mismatch, infer a polish type from a jacket color, or substitute an unspecified adapter.
OS2, OM3 and OM4 are separate listed fibre choices. The catalogue does not provide bandwidth, speed, wavelength or distance guarantees. Match the device documentation instead of assuming the higher number is the correct choice for every run.
FSF-003 is simplex; the other four cords are duplex. Verify the port arrangement and required path count. A mixed LC-SC cord changes connector formats between ends; it does not convert an optical signal or fibre type.
Lengths are fixed per SKU: 2 m, 3 m or 5 m as listed. Include the actual route, service access and installation limits. The 2.0 mm jacket notation does not supply a bend-radius or tensile-load rating.
| Task | Candidate | Check before requesting |
|---|---|---|
| Reusable retention | FSF-006 straps | 200 x 12 mm each; ten in the set; avoid compressing leads |
| Desk access | FSF-007 guide | Six slots; 120 x 28 x 18 mm body; cable fit is not specified |
| Bundle enclosure | FSF-008 sleeve | 1000 mm long; nominal 20 mm diameter; measure bundle |
| Individual route points | FSF-009 clips | 20 x 15 x 12 mm each; surface and adhesive suitability unverified |
| Rack route | FSF-010 panel | 19-inch 1U mounting; 60 mm depth; confirm clearance |
This is a selection aid, not an installation certification. For an unlisted requirement, describe your port pair, fibre, path count and route constraints to the shop before payment.
